Primary Application: Streetlighting

The Problem: When a large utility in downtown New York carried out a streetlight installation project (changing out 7M ballasts), they needed to quickly verify the installation without waiting for it to get dark to see the lights turn on.

The solution: Apply a light 10A load to the service to verify proper installation/lights turn on.

Smaller and more affordable than the Super Beast, the Mini Beast is quick and easy to use. Isolate street light ballasts and transformers to verify 120V circuit connection. Validate transformer installation and power quality, or troubleshoot 120V, 2-wire system setup and connection. 8 Amp load quickly verifies circuit installation.

NEW “Pulse” FEATURE

The “Pulse” is the NEW added feature to the Mini Beast.

Allows for cable identification/tracing by pulsing light load and tracking the rise/fall with an ampmeter

Adjustable pulse frequency (flathead screwdriver needed)

The Mini Beast Pulse comes with a hanging hook for operator convenience

Operation Instructions:

Simply connect the voltage clip to the secondary (120V) side of transformer and neutral clip to the neutral line. The volt meter will show the line voltage without a load. Flip switch to apply load, and compare the voltage readings under load.
