Salisbury Class 3 Rubber Sleeve, Red/Yellow, Dipped (Max Use: 26.5 kV)

Login to view prices

Shipping charge is added to invoice once known.

Typically STOCKED at Arnett

Call to confirm: (503)-692-4600 or email [email protected]

Price includes Dielectric Test with date stamp

SKU: S-D3- size -RY-EC Categories: , Tag:

NAIL accredited rubber goods test labRubber goods are stocked untested at Arnett. Rubber testing to NAIL4PET, OSHA & ASTM requirements available with additional cost.

Extra Curved, Dipped

Type I

Lineman’s Sleeves:

Rubber insulating sleeves extend coverage of the arm from the cuff of rubber insulating gloves to the shoulder; fully protecting these areas from accidental contact with energized conductors and equipment. Salisbury sleeves feature a reinforcing fold at the cuff. This fold is preferred over a rolled bead because it adds less bulk to the cuff and fits into the glove easier without pushing. Two different processes are used to manufacture insulating sleeves; dipping and molding. Both meet the current requirements of ASTM D1051 and offer the same high level quality and protection.

Dipped Sleeves:

Dipped sleeves are manufactured in the same way as Salisbury rubber insulating gloves. Porcelain forms are dipped into liquefied rubber, dried, trimmed, marked, and cured. Every sleeve receives the same quality inspections and electrical testing before shipping. Dipped sleeves are available in the same colors as dipped gloves, including two color combinations.

Salisbury offers two popular styles of dipped lineman’s sleeves: straight and extra-curved. Both styles are available in solid color or color combination, size and voltage class.

Molded Sleeves:

Molded sleeves are manufactured by either injection or compression molding methods. The advantage these methods offer is the ability to produce sleeves of Type 1 or SALCOR Type 2 synthetic rubber. SALCOR sleeves provide the same high quality and electrical protection as natural rubber, with the added benefit of being resistant to ozone and ultraviolet radiation. Type 1 sleeves are available in black, yellow, or maroon. Type 2 SALCOR sleeves are black or orange. Molded sleeves are available in curved arm style only.

General Care & Inspection of Rubber Goods:

Type I Natural (non-ozone resistant) and Type II SALCOR synthetic rubber (resistant to ozone) both provide electrical workers with the highest level of electrical insulating protection. However, in order to maintain this level of protection and ensure long life, it is essential that rubber goods are properly cared for. Before each use, rubber goods should be visually inspected for holes, embedded wires, rips or tears, ozone cutting, UV checking and signs of chemical deterioration. For additional information, refer to ASTM F1236, standard guide for visual inspection of electrical protective rubber products.

https://hjarnett.comconstage/services/rubber-glove-testing-lab/
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov

Style

,

ASTM Class

Color

Red (inside) / Yellow (outside)

Manufacturer

Salisbury by Honeywell

Voltage Rating

Test Voltage: 30,000V | Max Use Rating: 26,500V
