• Intelli‑CRIMP® technology notifies operator with a visual and audible alert in real
time if crimp force is not achieved
• Automatic Retraction Stop (ARS) retracts the ram just enough to get ready for the
next cycle, saving time and energy
• Accepts P‑style die to crimp splices and lugs up to 1500 kcmil copper and
1250 kcmil aluminum
• Accepts Kearney PH4/P14 dies without adapter
• Crimping head rotates 350°
• Includes UA15T U Die Adapter
SPECIFICATIONS
Crimping Force 15 Tons (135 kN)
Length 18‑1/2″ (470 mm)
Width 3‑1/8″ (80 mm)
Height 13‑1/2″ (343 mm)
Weight 16.3 lb (7.4 kg)
Capacity 8 AWG –1550 kcmil Cu lugs and splices
8 AWG –1250 kcmil Al lugs and splices
