The Chance Spiral Link Stick (C4000812) is used in lieu of a strain link stick in close places where the lineman cannot safely install a strain link stick by hand. A lifting eye on the head ferrule enables the lineman to guide the Spiral Link Stick to the conductor with a hotstick. The pole of the Spiral Link Stick is made of 11/4″ Epoxiglas®. Ferrule castings are of heat-treated aluminum alloy; spiral hook and butt ring of galvanized steel.
Arnett part# C-C4000812
| Product Type | Â Transmission Tools |
| Â Tool Type | Â Link Stick |
| Â Style | Â Spiral Link Stick |
| Â Diameter | Â 1.25″ (32 mm) |
| Â Length in (mm) | Â 42″ (1 m) |
| Â Duty | Â 3,500 lbs. (1588 kg) |
| Â Overall Length | Â 57.5″ (1.5 m) |
| Â Wire Size | Â 1510.5 kcmil ACSR |
| Â Material Type | Â Standard |
| Â UPC Code | Â 09635901683 |
| Â Standard Package | Â 1 |
| Â Standard Package Unit | Â Each |
| Â Min Order Qty | Â 1 |
| Â Weight / Ea. lbs | Â 10.094 lbs |
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
