ASTM Grade 5 T-handle Flat-Faced Grounding Clamp
| Â Product Type | Â Grounding Clamps |
| Â Configuration | Â Single Clamp |
| Â Product | Â Flat-Face Clamp |
| Â Jaw Opening Size (Maximum) | Â 1.5″ (38 mm) |
| Â Jaw Opening Size (Minimum) | Â 0.125″ (3 mm) |
| Â Fault Current Rating | Â ASTM Grade 5 |
| Â Material | Â Bronze |
| Â Terminal Type | Â 5/8″-11 Thread |
| Â Handle Type | Â T-Handle |
| Â Jaw Type | Â Serrated Jaws |
| Â Continuous Current | Â 400 Amps |
| Â Fault Current – 15 cycles | Â 43,000 Amps |
| Â Fault Current – 30 cycles | Â 30,000 Amps |
| Â Recommended Torque | Â 250 in-lbs (339 N-M) |
| Â Jumper Range – Maximum | Â 4/0 Cable w/ Threaded Terminal |
| Â Jumper Range – Minimum | Â #2 Cable w/ Threaded Terminal |
| Â Material Type | Â Standard |
| Â UPC Code | 096359453314 |
| Â Standard Package | Â 1 |
| Â Standard Package Unit | Â Each |
| Â Min Order Qty | Â 1 |
| Â Weight / Ea. | Â 2.666 lbs |
Chance part# T6003195
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
