Certified to OSHA dialectric requirements (Sub-part V, section 1926.951), these full-function Telescoping Tools does more than separate measuring sticks and disconnect tools. To measure pole heights and conductor clearances from the ground, this single tool is marked with both English and Metric scales.
Measuring scales are easy-to-read, large black figures silk-screened on Chance orange fiberglass sections. English scales are marked with each 1-foot increment designated in a box, each inch in bold numbers and half-inches designed by intermediate bars. Metric scales similarly display meters, decimeters and centimeters.
Removable disconnect head for operating switches and cutouts.
End fitting on insulated top section accepts other universal tool accessories for energized conductor applications, all from the ground.
| Product Type | Â Insulated Hand Tools |
| Â Tool Type | Â Telescoping Disconnect Tool |
| Â Style | Â Standard Duty |
| Â Length in (mm) | Â 35′ (10.7 m) Maximum |
| Â Measuring Units | Â English & Metric |
| Â Retracted Length | Â 67″ (1.7 m) |
| Â Extended Length | Â 22 – 26 – 30.5 – 35 ft. |
| Â Base Diameter | Â 2.5″ (63 mm) |
| Â Number of Sections | Â 8 |
| Â Storage Bag | Â P621-5 (Bag not included. Must be ordered separately.) |
| Â Material Type | Â Standard |
| Â UPC Code | Â 096359445128 |
| Â Standard Package | Â 1 |
| Â Standard Package Unit | Â Each |
| Â Min Order Qty | Â 1 |
| Â Weight / Ea. lbs | Â 10.78 lbs |
